控制与通讯
调速器由16位微控制器进行控制，具备如下高级功能：
复杂控制算法，简单模拟技术是不可能完成这种算法的。
可由软件配置的控制电路，构建在标准软件模块周围。
串行连接通讯，与其他驱动器或PC机进行通讯，用于高级处理系统。
通过操作站，可以获得参数、诊断性信息、跳闸保护设置以及全部应用编程的信息。
再生与非再生模式
电机电枢控制器包括再生与非再生两种模式：
反馈性控制器包括两个全控晶闸管桥和一个具有充分瞬时保护与过载保护功能的励磁电桥，以及加速与

减速、两个旋转方向上的速度与转矩的高级电子控制器。非反馈性控制器包括一个全控晶闸管桥和一个

具有充分瞬时保护与过载保护功能的励磁电桥，以及配套电子控制电路，并在一个选定的旋转方向上提

供精确的速度和/或转矩控制功能。励磁调节器，励磁调节器为标准配件。调节器包括具有瞬时保护与

过载保护功能的全波半控单相晶闸管桥。根据固定转矩应用所选定的运行模式的不同，励磁调节器可提

供固定电压或者固定电流源。可以进一步改善励磁电流的运行模式，从而为需要进一步进行速度或恒定

马力控制的调速器控制电机提供励磁弱化。
590+系列调速器被设计为在适用的电器柜中与控制装置结合使用。根据型号的不同，该调速器可使用各

种标准的三相交流供电压，并适合于为直流并激励磁以及永磁电机供电，为电枢以及励磁提供受控直流

输出电压和电流。所有设备均利用插销进行简单、节约成本的面板安装。插入式控制接头简化了该设备

与面板之间的安装与拆卸工作。只要有可能，便在整个范围内使用标准部件，以减少维护多驱动系统所

需要的各种不同备件的种类。例如，无论马力或电桥配置情况如何，所有类型的三相电枢控制器中均采

用相同的基本控制板。控制电路完全与电源电路分隔开来，这样，就简化了在一个系统内部的控制器之

间的交叉连接并提高了操作人员的安全程度。编码电路具备自动调整功能，能够适用45赫兹至65赫兹之

间的电源频率，并对电源本身的干扰具有较高的抗扰度。电枢控制器对相位旋转不敏感。
所有设备均可用作：
590+ : 四象限，三相、全控制、反平行晶闸管桥配置。
591+ : 二象限，三相、全控制晶闸管桥配置
