balluff巴鲁夫精准定位传感器BMS系列

balluff巴鲁夫精准定位传感器BMS系列
以*佳方式固定传感器
采用崭新实用设计、配有全新夹紧架的安装系统
BMS安装系统升级 – 保障安全固定
通用的安装系统BMS提供了一种崭新的设计方案，以便在应用中以*优化的方式简

便固定传感器。通过几个手柄就可以快速灵活地完成复杂的定位任务。
坚固耐用、用途广泛
固定技术专门为恶劣的工业环境而设计。各个部件能承受*的机械负荷 – 底

座支架、连接件和传感器支架 – 由坚固耐用的压铸锌制造而成。
操作简单
底座支架与各种供应商专用安装型材相匹配并可完全覆盖凹槽。在一侧用力压平

后，该支架也适合直接安装在墙面上。固定螺栓可从一侧触及。
连接件和传感器支架均可通过一个锁闩机械结构防滑安装在杆件上，分别只需一

个螺丝固定。
连接角度可以通过刻度调节。
新型夹紧架 – 无需使用工具
用于M12传感器、M18传感器和M30传感器的巴鲁夫新款夹紧架操作非常简便。没有

工具也可以使用。
装上传感器后，用手拧紧滚花螺母即可牢固固定。
对于特殊的环境条件，比如高温或强振时，可以用开口扳手再次拧紧滚花螺母。
夹紧架不含塑料部件。因此可适用于温度高达500 °C的使用环境
联系人：肖工
订货热线：
QQ：---
邮箱：
我公司备有大量现货，价格从优，欢迎新老客户来电垂询！
balluff巴鲁夫精准定位传感器BMS系列
BAM002H
BMS AD-P-001-12/10, Diameter 12 to 10 mm, Reduction,Material POM
BAM002J
BMS CU-P-D12-A040-00, Use with rods ?12 mm/10x10 mm
BAM002K
BMS CS-P-D12-AD08-00, Use with rods ?12 mm/10x10 mm
BAM002L
BMS CR-P-D12-AU-00, Use with rods ?12 mm/10x10 mm
BAM002M
BMS CC-P-D12-A-00, Cross connector for ?12 mm
BAM002N
BMS CS-P-D12-AD12-00, Use with rods ?12 mm/10x10 mm
BAM002P
BMS CS-P-D12-AD18-00, Use with rods ?12 mm/10x10 mm
BAM002R
BMS RS-M-D12-0150-00, Rod used with BMS ?12 mm,Housing material

Aluminum
BAM002T
BMS RS-M-D12-0250-00, Rod used with BMS ?12 mm,Housing material

Aluminum
BAM002U
BMS RS-M-D12-1000-00, Rod used with BMS ?12 mm,Housing material

Aluminum
BAM002W
BMS CU-M-D12-A040-00, Mounting rods ?12 mm
BAM002W
BMS CU-M-D12-A040-00, Basic holder
BAM002Y
BMS CUJ-P-D12-R040-00, Mounting rods ?12 mm,Housing material PA
BAM002Z
BMS CC-M-D12-B-00, Mounting rods ?12 mm,Housing material Aluminum
BAM0030
BMS CS-M-D12-BX01-01, Use with sensors BOS 25
BAM0031
BMS CS-M-D12-IZ, Basic holder
BAM0032
BMS CS-M-D12-ID18-01, Use with sensors M18x1,Housing material V4A
BAM0033
BMS CS-M-D12-ID30-01, For sensors M30x1.5,Housing material V4A
BAM0034
BMS CR-M-D12-IU-02, Reflectors BOS R-1,R-2,R-3
BAM0035
BMS CR-M-D12-IS-03, Use with reflector BOS R-11,Housing material V4A
BAM0036
BMS CS-M-D12-ID08-01, With clp.holder BES 05,0-KH-..
BAM0037
BMS CS-M-D12-ID12-01, With clp.holder BES 08,0-KH-..
Use with sensors M12x1,Housing material V4A
BAM0038
BMS AD-M-002-D12/D18, use with Laser sensors ?18 mm,Housing material

V2A
BAM0039
BMS BS-M-D12-0250-02, Mounting sensors BOS/Q08
BAM003A
BMS BS-M-D12-0250-01, Mounting reflectors R14
BAM003C
BMS CS-M-D12-BX05-02, Use with sensor series BOS 21M
BAM003C
not available
BMS CS-M-D12-BX05-02, Use with sensor series BOS 21M
BOS 25K, BOS 26K, BOS 50K
BAM003E
BMS AD-M-002-D12/D12, Mounting Laser sensors ?12 mm,Housing material

V2A
BAM003F
BMS BS-M-D12-0250-03, Mounting BGL 30A/50A/80A
BAM003H
BMS BS-M-D12-0400-04, Mounting BGL 180A/220A
BAM003J
BMS AD-M-003-D12/IZ, for connecting
BAM003K
BMS CS-M-D12-ID16-01, With clp.holder BES 12,0-KH-..
BAM003L
BMS CS-M-D12-ID24-01, With clp.holder BES 18,0-KH-..
BAM003M
BMS CS-M-D12-ID36-01, With clp.holder BES 30,0-KH-..
BAM003N
BMS CR-M-D12-IU-05, Use with reflector BOS R-1,Housing material V4A
BAM003P
BMS CS-M-D12-IQ40-02, Use with Unicompact, Unisensor
BAM003R
BMS CS-M-D12-IQ40-03, Use with Unicompact, Unisensor
BAM003U
BMS CC-P-D10-A-00, Cross connector for ?10 mm
BAM003Y
BMS CS-M-D12-IZ-01, Basic holder
Protection cap Unicompact BAM003Z
BMS CZ-M-B-001, Mounting sensor holder BAM003C
BAM0040
BMS CS-M-D12-BX06-03, Use with BOS 2K, BOS 5K,BOS 6K,Housing material

V4A
Beam deflector BAM0041
BMS CZ-M-D12-I-001, Blowing out sens. & reflectors,Housing material

Aluminum, plastic
BAM0042
BMS CR-M-D12-IS-04, Use with reflector BOS 21-AD-1
BAM0043
BMS CS-M-D12-B21K-04, Use with BOS 21,Housing material Zinc
BAM0044
BMS CU-M-D12-I060-01, Mounting BMS CS-M-D12-IZ,Housing material V2A
BAM0045
BMS RS-S-D12-0150-00, Rod used with BMS ?12 mm,Housing material V4A

1.4571
BAM0046
BMS RS-S-D12-0300-00, Rod used with BMS ?12 mm,Housing material V4A

1.4571
BAM01AW
BMS CS-M-D12-B23K-05, Use with BOS 23K, BOS 26K,Housing material V4A
BAM01AY
BMS CS-M-D12-BX07-06, Use with reflector BOS R-11
BAM01CH
BMS CU-M-D12-I060-02, Mounting BMS CS-M-D12-IZ,Housing material V2A
BAM01CW
BMS CS-M-D12-BX08-07, Mounting rods ?12 mm
BAM01F2
BMS CS-M-D12-BX11-09, Back lights
BAM01F3
BMS CS-M-D12-BX10-08, Sensors BWL 40/40, 54/54
BAM01J2
BMS CS-M-D12-IX09-01, Clp.hold. BES30,0-KH-..,BCS?50
BAM01J9
BMS CS-M-D12-IX12-02, For Quadro? MINI / Microscan,Housing material V4A
BAM01TK
BMS CS-M-D12-IX13-01, Mounting BAM PC-VS-008-1,Housing material V2A
BAM01UL
BMS CS-M-D12-IX14-01, Use with sensors BCS Q40...,Material Stainless

steel
Adapter BAM01YP
BMS CS-M-S25-DX15-00, Use with BAM01YT
Adapter BAM01YT
BMS CUJ-M-S25-D045-00, Use with BAM01YP,Material Aluminum
BAM01Z7
BMS CS-M-D14-IZ, Basic holder
BAM01Z8
BMS CS-M-D14-IZ-01, Basic holder
BAM021T
BMS RS-M-D12-0200-00, Rod used with BMS ?12 mm,Housing material

Aluminum
BAM021U
BMS RS-M-D12-0750-00, Rod used with BMS ?12 mm,Housing material

Aluminum
BAM021W
BMS RS-M-D12-0300-00, Rod used with BMS ?12 mm,Housing material

Aluminum
BAM021Y
BMS RS-M-D12-0100-00, Rod used with BMS ?12 mm,Housing material

Aluminum
BAM022C
BMS CS-M-D12-S6K-00, MB-XO, Use with series 6K,Material Anodized

aluminum
BAM024P
BMS CU-M-D12-B028-00, Mounting rods ?12 mm,Housing material GD-Zn
BAM024R
BMS CCJ-M-D12-B-01, Mounting rods ?12 mm,Housing material GD-Zn
BAM024T
BMS CS-M-D12-BZ, Mounting adapter plate
BAM0275
BMS CU-M-D12-B040-00, Mounting rods ?12 mm,Housing material GD-Zn
BAM0277
BMS CS-M-D12-BX17-11, Use with line lights,Material Stainless steel
BTL134F
BTL7-E500-M0813-BM-S32, Series Rod, Analog interface, current,

Connector, Supply voltage 10.0...30.0
BTL1HAM
BTL7-S502-M1200-BM-S32, Series Rod, SSI-Interface, Binary, 24 Bit,

Connector, Supply voltage 10.0...30.0
BTL1HAY
BTL7-S512-M1200-BM-S32, Series Rod, SSI-Interface, Gray, 24 Bit,

Connector, Supply voltage 10.0...30.0
