欧陆调速器591P系列的工作原理

欧陆调速器591P系列的工作原理
特点
•反馈性控制器包括两个全控晶闸管桥和一个具有充分瞬时保护与过载保护功能的励磁电

桥，以及加速与减速、
两个旋转方向上的速度与转矩的高级电子控制器。
　•非反馈性控制器包括一个全控晶闸管桥和一个具有充分瞬时保护与过载保护功能的

励磁电桥，以及配套电子
控制电路，并在一个选定的旋转方向上提供精确的速度和/或转矩控制功能。
励磁调节器
励磁调节器为标准配件。调节器包括具有瞬时保护与过载保护功能的全波半控单相晶闸

管桥。根据固定转矩应
用所选定的运行模式的不同，励磁调节器可提供固定电压或者固定电流源。可以进一步

改善励磁电流的运行模
式，从而为需要进一步进行速度或恒定马力控制的调速器控制电机提供励磁弱化。
工作原理
简单来说，调速器利用控制回路来控制直流调速器——一个内部电流回路与一个外部速

度回路。在应用
程序框图中，可以看到这些控制回路。该框图显示了所有调速器的软件连接情况。
利用操作站，您可以选择调速器要使用的控制回路，调速器将利用此控制回路来提供如

下两者之一：
•电流控制
•速度控制（默认设置）
为了更有效地控制调速器，通常向相应的回路提供电流或者速度反馈信号。电流反馈传

感器为内置式设计，而
速度反馈则直接从电枢传感电路（默认设置）提供，或者由模拟测速发电机以及连接到

相关的选项板上的编码
器或者微型测速器提供速度反馈。
在速度控制模式下
，您可以通过进一步控制电机励磁来修改调速器的性能，例如，励磁控制。通过弱化励

磁电流，您可以获得高于直流电机的额定电枢电压正常情况下可以获得的电机速度。
利用数字/模拟输入与输出可以远程控制调速器，或者利用操作站对调速器进行本地控制

。
通过插入通讯选项技术盒，可以将调速器连接到网络上，并由PLC/SCADA或其他智能设备

来控制。
