590+系列直流传动与690+变频器同属高性能传动家族,都提供自定义编程和设置等功能,具有相

同的通讯接口模块.590+高性能工程型直流传动
可以满足*复杂的直流电机控制要求.功能详尽的应用软件(其中卷曲控制作为标准配置),模块

化编程以及可自定义的I/O使590+单传动模块就
可以构成完整的传动控制方案.
友好的用户界面:
6901人机界面用于参数设置,编程和传动控制.液晶显示32个字符,带背景光,可以按字母顺序菜

单显示以便快速查阅所有功能模块.
.可分离的通用的控制盘,便于控制盘成柜安装
.提供本地的速度,启停,点动和转向控制
.用户可自定义显示内容和图标
.密码设置保护功能
.快速设置菜单
联网方便:
通讯接口模块可以直接安插在传动装置上,使用户能够通过各种标准现场总线网络监控传动系

统.可选的通
讯:LINK,DeviceNET,Controlnet,ProfiBus,ModBus,ModBus

Plus,Ethernet,CANopen,LonWorks.
功能强大，完善：
使用内置的软件功能模块几乎可以无限制地满足任何传动要求。所有功能模块都是预先编制好

的。通过控制盘或CELITE+软件,所有的功能模块
都可以内部连接用来实现某种特定的功能.功能模块包括:
.输入模块
.输出模块
.斜坡模块
.加减速模块
.卷曲功能(开卷/收卷卷径计算,力矩,补偿计算)
.PID控制
.磁场控制
.电动/松弛控制.
技术规格:
功率配置
590+四象限逆变回馈型:2个全控3相晶闸管桥;
591+二象限非逆变回馈型：1个全控3相晶闸管桥；
晶闸管控制可调磁场。
电枢电流
规格1：15A,35A
规格2: 40A,70A,110A,165A
规格3: 180A,270A
规格4: 380A,500A,725A,830A
规格5: 1580A
规格H: 1200A,1700A,2200A,2700A
过载能力:电流为15-450A传动,200%过载*长10秒钟;150%过载,*长30秒钟.大于700A规格,不

同规格有不同的过载能力,请参见手册.
电枢电压:Varmature(max)=Vac * 1.2
供电电源：
110--220V(正负10%),规格1-5选项；
220--500V(正负10%),规格1-5选项;
500--600V(正负10%),规格4-5选项；
500--690V(正负10%),规格H选项.
磁场电流:
规格1:4A;     规格2-3:10A;
规格4-5:30A;  规格H:60A.
磁场电压:Vfield(max)=Vac * 0.9
环境温度：0-45度，<270A的规格;0-40度,>270A的规格.超过上限,温度每升高1度,降容1%.*

高环境温度为55度
海拔:500米以下正常使用,超过500米,每升高200米,降容1%,*高为5000米.
模拟输入:5个(1个12bits精度带符号，4个10bits精度带符号） 1个速度给定（正负10V DC),4

个可自定义.
模拟输出:3个(10bits A/D转换精度） 1个电枢电流输出（正负10V 或者0-10V),2个可自定义.
数字输入:9个(24V DC,*大15A） 1个程序控制停止，1个惯性停车，1个外部信号停车，1个启

停，5个可自定义。
数字输出：3个（24V  100MA) 3个可自定义.
参考电压输入:3个,-10V DC/10V DC/24V DC
联系人：肖工

QQ：---
邮箱：
我公司备有大量现货，价格从优，欢迎新老客户来电垂询！
派克SSD590+可逆直流调速器,派克直流调速器接线图
590SPD2706AA
590SPD2706BA
590SPL2706AA
590SPL2706BA
591SPD2706AA
591SPD2706BA
591SPL2706AA
591SPL2706BA
955SPD-4N51
955SPL-4N51
955SPD-4R51
955SPL-4R51
955+8N0007/0/UK/ARM/110
955+8N0007/0/UK/ARM/220
955+8N0007/1/UK/ARM/110
955+8N0007/1/UK/ARM/220
955+8N0020/0/UK/ARM/110
955+8N0020/0/UK/ARM/220
955+8N0020/1/UK/ARM/110
955+8N0020/1/UK/ARM/220
955+8N0025/0/UK/ARM/110
955+8N0025/0/UK/ARM/220
955+8N0025/1/UK/ARM/110
955+8N0025/1/UK/ARM/220
955+8N0040/0/UK/ARM/110
955+8N0040/0/UK/ARM/220
955+8N0040/1/UK/ARM/110
955+8N0040/1/UK/ARM/220
955+8N0060/0/UK/ARM/110
955+8N0060/0/UK/ARM/220
955+8N0060/1/UK/ARM/110
955+8N0060/1/UK/ARM/220
955+8N0100/0/UK/ARM/110
955+8N0100/0/UK/ARM/220
955+8N0100/1/UK/ARM/110
955+8N0100/1/UK/ARM/220
955+8R0007/0/UK/ARM/110
955+8R0007/0/UK/ARM/220
955+8R0007/1/UK/ARM/110
955+8R0007/1/UK/ARM/220
955+8R0020/0/UK/ARM/110
955+8R0020/0/UK/ARM/220
955+8R0020/1/UK/ARM/110
955+8R0020/1/UK/ARM/220
955+8R0025/0/UK/ARM/110
955+8R0025/0/UK/ARM/220
955+8R0025/1/UK/ARM/110
955+8R0025/1/UK/ARM/220
955+8R0040/0/UK/ARM/110
955+8R0040/0/UK/ARM/220
955+8R0040/1/UK/ARM/110
955+8R0040/1/UK/ARM/220
955+8R0060/0/UK/ARM/110
955+8R0060/0/UK/ARM/220
955+8R0060/1/UK/ARM/110
955+8R0060/1/UK/ARM/220
955+8R0100/0/UK/ARM/110
955+8R0100/0/UK/ARM/220
955+8R0100/1/UK/ARM/110
955+8R0100/1/UK/ARM/220
590A/0350 35A Four Quadrant Analogue Drive
590A/0700 70A Four Quadrant Analogue Drive
590A/1100 110A Four Quadrant Analogue Drive
590A/1500 150A Four Quadrant Analogue Drive
590A/1800 180A Four Quadrant Analogue Drive
590A/2700 270A Four Quadrant Analogue Drive
590A/3600 360A Four Quadrant Analogue Drive
590A/4500 450A Four Quadrant Analogue Drive
590A/7200 720A Four Quadrant Analogue Drive
590A/8000 Option 24 800A Four Quadrant Analogue Drive
591A/0350 35A Two Quadrant Analogue Drive
591A/0700 70A Two Quadrant Analogue Drive
591A/1100 110A Two Quadrant Analogue Drive
591A/1500 150A Two Quadrant Analogue Drive
591A/1800 180A Two Quadrant Analogue Drive
591A/2700 270A Two Quadrant Analogue Drive
591A/3600 360A Two Quadrant Analogue Drive
591A/4500 450A Two Quadrant Analogue Drive
591A/7200 720A Two Quadrant Analogue Drive
591A/8000 Option 24 800A Two Quadrant Analogue Drive
590LC/0350 35A Four Quadrant Link Drive
590LC/0700 70A Four Quadrant Link Drive
590LC/1100 110A Four Quadrant Link Drive
590LC/1500 150A Four Quadrant Link Drive
590LC/1800 180A Four Quadrant Link Drive
590LC/2700 270A Four Quadrant Link Drive
590LC/3600 360A Four Quadrant Link Drive
590LC/4500 450A Four Quadrant Link Drive
590LC/7200 720A Four Quadrant Link Drive
590LC/8000 Option 24 800A Four Quadrant Link Drive
591LC/0350 35A Two Quadrant Link Drive
591LC/0700 70A Two Quadrant Link Drive
591LC/1100 110A Two Quadrant Link Drive
591LC/1500 150A Two Quadrant Link Drive
591LC/1800 180A Two Quadrant Link Drive
591LC/2700 270A Two Quadrant Link Drive
591LC/3600 360A Two Quadrant Link Drive
591LC/4500 450A Two Quadrant Link Drive
591LC/7200 720A Two Quadrant Link Drive
591LC/8000 Option 24 800A Two Quadrant Link Drive
590HA/12000 1200A / 500V Four Quadrant Analogue Drive
590HA/12000 1200A / 690V Four Quadrant Analogue Drive
590HA/17000 1700A / 500V Four Quadrant Analogue Drive
590HA/17000 1700A / 690V Four Quadrant Analogue Drive
590HA/22000 2200A / 500V Four Quadrant Analogue Drive
590HA/22000 2200A / 690V Four Quadrant Analogue Drive
590HA/27000 2700A / 500V Four Quadrant Analogue Drive
590HA/27000 2700A / 690V Four Quadrant Analogue Drive
591HA/12000 1200A / 500V Two Quadrant Analogue Drive
591HA/12000 1200A / 690V Two Quadrant Analogue Drive
591HA/17000 1700A / 500V Two Quadrant Analogue Drive
591HA/17000 1700A / 690V Two Quadrant Analogue Drive
591HA/22000 2200A / 500V Two Quadrant Analogue Drive
591HA/22000 2200A / 690V Two Quadrant Analogue Drive
591HA/27000 2700A / 500V Two Quadrant Analogue Drive
591HA/27000 2700A / 690V Two Quadrant Analogue Drive
590HD/12000 1200A / 500V Four Quadrant Digital Drive
590HD/12000 1200A / 690V Four Quadrant Digital Drive
590HD/17000 1700A / 500V Four Quadrant Digital Drive
590HD/17000 1700A / 690V Four Quadrant Digital Drive
590HD/22000 2200A / 500V Four Quadrant Digital Drive
590HD/22000 2200A / 690V Four Quadrant Digital Drive
590HD/27000 2700A / 500V Four Quadrant Digital Drive
590HD/27000 2700A / 690V Four Quadrant Digital Drive
591HD/12000 1200A / 500V Two Quadrant Digital Drive
591HD/12000 1200A / 690V Two Quadrant Digital Drive
591HD/17000 1700A / 500V Two Quadrant Digital Drive
591HD/17000 1700A / 690V Two Quadrant Digital Drive
591HD/22000 2200A / 500V Two Quadrant Digital Drive
591HD/22000 2200A / 690V Two Quadrant Digital Drive
591HD/27000 2700A / 500V Two Quadrant Digital Drive
591HD/27000 2700A / 690V Two Quadrant Digital Drive
590HL/12000 1200A / 500V Four Quadrant Link Drive
590HL/12000 1200A / 690V Four Quadrant Link Drive
590HL/17000 1700A / 500V Four Quadrant Link Drive
590HL/17000 1700A / 690V Four Quadrant Link Drive
590HL/22000 2200A / 500V Four Quadrant Link Drive
590HL/22000 2200A / 690V Four Quadrant Link Drive
590HL/27000 2700A / 500V Four Quadrant Link Drive
590HL/27000 2700A / 690V Four Quadrant Link Drive
591HL/12000 1200A / 500V Two Quadrant Link Drive
591HL/12000 1200A / 690V Two Quadrant Link Drive
591HL/17000 1700A / 500V Two Quadrant Link Drive
591HL/17000 1700A / 690V Two Quadrant Link Drive
591HL/22000 2200A / 500V Two Quadrant Link Drive
591HL/22000 2200A / 690V Two Quadrant Link Drive
591HL/27000 2700A / 500V Two Quadrant Link Drive
591HL/27000 2700A / 690V Two Quadrant Link Drive
AH385826U001
AH386025U002
AH385457U001
AH385870U001
AH386025U001
AH387775U001
AH389918U001
AH467328U001
LA467108
LA467108U001
CI055069
CI055070
CM056316U020
CM056316U050
CM056316U100
CM059748U050
CM059748U200
CH571253
CH590404
CP051603
CS051606
FUSEHOLDERS
CP059914
DB058253
DB058254
DB389712
DB058255
DB058256
CP059912
LA042453
CO055192
CO055193
CO055253
CO055255
CO057960
CO387886
CO057962
CO057963
DC ARMATURE CHOKES
CO356413
CO356414
CO356415
CO356416
CO356417
CO356418
CO356363
CO356364
CO356365
CO356401
CO057049
CO389114
CO388965U035
CO388965U110
CO388965U180
CO389456
CO389456 (2 OFF)
CO389456 (3 OFF)
CO389456 (4 OFF)
CO389456 (5 OFF)
CO389456 (7 OFF)
CO389456 (8 OFF
THREE PHASE AC LINE CHOKES FOR USE WITH ABOVE TO ACHIEVE EMC COMPLIANCE
CO463036
CO463037
CO463038
CO463039
CO057960
CO387886
CO057962
CO057963
506/00/20/00
507/00/20/00
508/00/20/00
512C/040/00
512C/080/00
512C/160/00
512C/320/00
514C/040/00
514C/080/00
514C/160/00
514C/320/00
LA050063
FUSE KITS
LA054664
LA050062
LA057605U012
LA057605U016
LA057605U032
LA057605U050
FUSES
CH390123
CH390163
CH390323
CH390054
CH230014
CH230024
RFI FILTERS
CO389115
CO389113
CO389114
SETPOINT ISOLATOR
LA464345U002
LA464345U00
